商品の詳細:
|
| 構造: | VPSA酸素ジェネレーター産業用 | テスト圧力: | 0.8MPA-1.6MPA |
|---|---|---|---|
| プロセス: | VPSA | 操作モード: | 自動 |
| 容量: | 5-5000 nm3/h | 電圧: | 220V/380V/50-60Hz |
| 窒素出力: | ≤300Nm3/hr | 消費: | 省エネ |
| 外容器素材: | 炭素鋼 | 動作圧力: | 0.1-0.6 MPa |
| オイル含有量: | オイルフリー | 動作電源: | 1 kW |
| 純度: | 90-95% | キーワード: | VPSAの酸素の発電機 |
| ハイライト: | PSA oxygen generator with warranty,VPSA oxygen generator for industrial use,cryogenic oxygen generator small large |
||
Purity: 90%-93%
Capacity: 200~20000Nm3/h
Pressure: Normal 0.4Mpa
Energy for Consumption Oxygen: 0.36~0.42KWh/Nm
The VPSA precess is similar with PSA. VPSA oxygen generator use air blower to supply compressed air into a adsorption tower, adsorption in low pressure and adsorption in vacuum status. Under atmosphere or slightly abover atmosphere pressure, using mixed bed composed of VPSA special molecular sieve and dryer to absorb the N2,CO2.H2O and other impurities, making oxygen accumulated and collected at the end of bed. Saturation sorption of molecular sieve bed will be desorbed in vacuum status, so as to circularly generate high purity Oxygen (90~95%).
Compared with PSA process, VPSA has complex process equopment and higher investment but low power consumption, suitable for large scale oxygen production.
| Gas production m³/h | Oxygen concentration% | Oxygen pressure Mpa | Power 220V Power/kw | Host weight/kg | Dimensions/mm | Air loss factor | Number of bottles per day 40L/120-150kg |
|---|---|---|---|---|---|---|---|
| 3 | 93±3 | 0.4±0.1 | 0.2 | 600 | 15009001500 | 13.5 | 12-15 |
| 5 | 93±3 | 0.4±0.1 | 0.2 | 900 | 16009001500 | 13.5 | 20-24 |
| 10 | 93±3 | 0.4±0.1 | 0.2 | 1200 | 16009001900 | 13.5 | 40-48 |
| 20 | 93±3 | 0.4±0.1 | 0.2 | 1500 | 190010002180 | 13.5 | 80-96 |
| 30 | 93±3 | 0.4±0.1 | 0.2 | 2000 | 200011002180 | 13.5 | 120-154 |
| 40 | 93±3 | 0.4±0.1 | 0.2 | 2500 | 260012002300 | 13.5 | 160-192 |
| 50 | 93±3 | 0.4±0.1 | 0.5 | 2800 | 180015002400+800 | 13.5 | 200-240 |
| 60 | 93±3 | 0.4±0.1 | 0.5 | 3200 | 180015002600+800 | 13.5 | 240-184 |
| 70 | 93±3 | 0.4±0.1 | 0.5 | 3500 | 180016002800+800 | 13.5 | 280-236 |
| 80 | 93±3 | 0.4±0.1 | 0.5 | 4000 | 180016002900+1000 | 13.5 | 320-394 |
| 90 | 93±3 | 0.4±0.1 | 0.5 | 4800 | 200016002800+1000 | 13.5 | 360-432 |
| 100 | 93±3 | 0.4±0.1 | 0.5 | 5800 | 220016002900+1000 | 13.5 | 400-480 |
| 120 | 93±3 | 0.4±0.1 | 0.5 | 6500 | 240016003100+1000 | 13.5 | 480-576 |
| Size | 123 (L) * 456 (W) * 789 (D) |
| Weight | 1.2 T |
| Packaging Details | The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request. |
In addition to PSA Oxygen Generators, we also produce VPSA Oxygen Generators, storage tanks, heat exchangers and other products. If you are interested in VPSA Oxygen Systems or other products, please feel free to send an email to info@gneeheatex.com. We will be very happy to serve you.
