商品の詳細:
|
| テクノロジー: | 圧力スイングadsorbtion（PSA） | 電源: | 380V/50Hz |
|---|---|---|---|
| 容量: | 1000LPM | 騒音レベル: | ≤75dB |
| 保証: | 12ヶ月 | 力: | 76-138KW(軸出力) |
| 生産能力: | 1か月あたり1500セット | 作業原則: | 圧力スイング吸着 |
| 仕事の率: | 90W | パッケージ: | 耐航性のある梱包 |
| 酸素純度: | 93%+-3% | 大気の露点: | ≤−46°C |
| ハイライト: | 40 Nm³/h PSA Oxygen Generator,316L Stainless Steel PSA Oxygen Generator,12 Months Warranty PSA Oxygen Generator |
||
The PSA Oxygen Gas Generator is an industrial oxygen supply equipment specifically designed for corrosive environments. Utilizing pressure swing adsorption technology with corrosion-resistant materials and specialized molecular sieves, this system delivers stable oxygen supply with reliable operation in harsh conditions.
| Gas production (m³/h) | Oxygen concentration (%) | Oxygen pressure (Mpa) | Power (220V/kw) | Host weight (kg) | Dimensions (mm) | Air loss factor | Number of bottles per day (40L/120-150kg) |
|---|---|---|---|---|---|---|---|
| 3 | 93±3 | 0.4±0.1 | 0.2 | 600 | 1500×900×1500 | 13.5 | 12-15 |
| 5 | 93±3 | 0.4±0.1 | 0.2 | 900 | 1600×900×1500 | 13.5 | 20-24 |
| 10 | 93±3 | 0.4±0.1 | 0.2 | 1200 | 1600×900×1900 | 13.5 | 40-48 |
| 20 | 93±3 | 0.4±0.1 | 0.2 | 1500 | 1900×1000×2180 | 13.5 | 80-96 |
| 30 | 93±3 | 0.4±0.1 | 0.2 | 2000 | 2000×1100×2180 | 13.5 | 120-154 |
| 40 | 93±3 | 0.4±0.1 | 0.2 | 2500 | 2600×1200×2300 | 13.5 | 160-192 |
| 50 | 93±3 | 0.4±0.1 | 0.5 | 2800 | 1800×1500×2400+800 | 13.5 | 200-240 |
| 60 | 93±3 | 0.4±0.1 | 0.5 | 3200 | 1800×1500×2600+800 | 13.5 | 240-184 |
| 70 | 93±3 | 0.4±0.1 | 0.5 | 3500 | 1800×1600×2800+800 | 13.5 | 280-236 |
| 80 | 93±3 | 0.4±0.1 | 0.5 | 4000 | 1800×1600×2900+1000 | 13.5 | 320-394 |
| 90 | 93±3 | 0.4±0.1 | 0.5 | 4800 | 2000×1600×2800+1000 | 13.5 | 360-432 |
| 100 | 93±3 | 0.4±0.1 | 0.5 | 5800 | 2200×1600×2900+1000 | 13.5 | 400-480 |
| 120 | 93±3 | 0.4±0.1 | 0.5 | 6500 | 2400×1600×3100+1000 | 13.5 | 480-576 |
Specially engineered for pharmaceutical wastewater treatment environments, this PSA Oxygen Gas Generator incorporates advanced corrosion protection:
The system integrates with wastewater treatment PLC systems for automatic oxygen flow adjustment based on real-time COD monitoring:
Specialized maintenance protocols ensure optimal performance in corrosive environments:
Annual maintenance agreements with the manufacturer can extend equipment lifespan to 6+ years through specialized corrosion protection treatments.
In addition to PSA Oxygen Generators, we also produce VPSA Oxygen Generators, storage tanks, and heat exchangers. For inquiries about VPSA Oxygen Systems or other products, please contact us at info@gneeheatex.com.
