商品の詳細:
|
| Height: | 2591mm | Capacity: | 1000 liters |
|---|---|---|---|
| Max Working Pressure: | 2.16mpa | Temperature Range: | -196°C to 120°C |
| Pressure Rating: | 1.6 MPa | Design Standard: | SGS/ASME |
| Outer Material: | Q345R | Operating Pressure: | 1.6MPa |
| Geometric Volume: | 15.07m3 | Working Years Design: | 20years |
| ハイライト: | 1000L underground oil storage tank,ASME standard fuel storage tank,cryogenic oil storage tank |
||
| Attribute | Value |
|---|---|
| Height | 2591mm |
| Capacity | 1000 liters |
| Max Working Pressure | 2.16mpa |
| Temperature Range | -196°C to 120°C |
| Pressure Rating | 1.6 MPa |
| Design Standard | SGS/ASME |
| Outer Material | Q345R |
| Operating Pressure | 1.6MPa |
| Geometric Volume | 15.07m3 |
| Working Years Design | 20 years |
Our Oil Fuel Storage Tanks are designed and manufactured based on the ASME VIII-1 code, meeting the requirements of ASME, PED, AS1210 and other international standards. We specialize in customized pressure vessels including oil storage tanks, petrol storage tanks, air receivers, absorption tanks, and filter tanks.
| Volume (lt) | Inner Diameter (mm) | Total Height (mm) | Cylindrical Height (mm) |
|---|---|---|---|
| 1000 | 930 | 2200 | 1500 |
| 2000 | 1270 | 2600 | 1610 |
| 3000 | 1400 | 2900 | 2000 |
| 4000 | 1600 | 3100 | 2000 |
| 5000 | 1600 | 3700 | 2440 |
| 10000 | 1900 | 5050 | 3660 |
| 15000 | 2000 | 5950 | 4880 |
| 20000 | 2230 | 6100 | 5110 |
| 25000 | 2650 | 5600 | 4500 |
| 30000 | 2600 | 6760 | 5500 |
Our company is a professional manufacturer of large storage tanks, offering comprehensive services including design, material provision, and overseas installation. Our professional engineers and construction teams ensure all tanks meet international standards.
